PRECISION HOLDERS
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Bilz BILZ BT40 Super Collet Chuck
Application:?For high-speed spindles and general millingMachine types:?Machine Centers FEATURES Excellent Run-out accuracy? within? 5? @ 4D Gripping force double than ER Integrated run-out accuracy with compact design Dynamically balanced G2.5 @ 25000rpm Minimize the work interruption between tool and work piece Super Collet Vs ER Collet SUPER COLLET Slim design allows for better each Force is perpendicular to center line of tool holder for better grip Integrated run-out accuracy with compact design More gripping area creates better accuracy ER COLLET Wide collets = wide nut design Force is angular to center line of tool holder Less gripping area results in lesser accuracy Super Collet chuck - Advantages ? SUPER COLLET slim design allows for better reach Force is perpendicular to center line of tool holder for better grip More gripping area creates better accuracy ER? COLLET Wide collets = wide nut design Force is angular to center line of tool holder Less gripping area results in lesser accuracy
-
Bilz BILZ BT50 Super Collet Chuck
Application:?For high-speed spindles and general millingMachine types:?Machine Centers FEATURES Excellent Run-out accuracy? within? 5? @ 4D Gripping force double than ER Integrated run-out accuracy with compact design Dynamically balanced G2.5 @ 25000rpm Minimize the work interruption between tool and work piece Super Collet Vs ER Collet SUPER COLLET Slim design allows for better each Force is perpendicular to center line of tool holder for better grip Integrated run-out accuracy with compact design More gripping area creates better accuracy ER COLLET Wide collets = wide nut design Force is angular to center line of tool holder Less gripping area results in lesser accuracy Super Collet chuck - Advantages ? SUPER COLLET slim design allows for better reach Force is perpendicular to center line of tool holder for better grip More gripping area creates better accuracy ER? COLLET Wide collets = wide nut design Force is angular to center line of tool holder Less gripping area results in lesser accuracy
-
-
-
-
-
-
-
-
-
-
Bilz BILZ BT40 Micro Collet Chuck Holder
The BILZ BT40 Micro Collet Holder ensures precise accuracy of your micro collet with its advanced engineering and reduced tolerance down to 0.005 microns. Its superior design ensures the highest level of precision.
