The Nicon Low Profile Side Clamp is a compact and efficient work holding solution designed to securely clamp workpieces from the side, leaving the top surface completely accessible for machining operations. Its low-profile design makes it ideal for CNC milling, grinding, drilling, and precision machining applications where unobstructed access is essential.
Manufactured from high-quality alloy steel and hardened to HRC 55 ±2, the clamp offers excellent strength, wear resistance, and long service life. The integrated dovetail clamping mechanism provides a strong lateral clamping force while preventing workpiece lift during machining, ensuring maximum stability and accuracy.
Technical Specifications
Model
Length (L)
Width (W)
Height (H)
H1
C
D Thread
E Thread
LPC-32
115 mm
32 mm
32 mm
12 mm
—
M10
M8
LPC-50
160 mm
50 mm
50 mm
14 mm
25 mm
M12
M10
Key Features
Side Clamping Design – Holds the workpiece laterally, keeping the entire top surface free for machining.
Low Profile Construction – Ideal for applications with limited space and multi-part setups.
High Clamping Force – Delivers secure holding power for reliable machining performance.
Anti-Lift Dovetail Mechanism – Minimizes workpiece movement and prevents lifting under cutting forces.
Precision Ground Surfaces – Ensures accurate positioning and repeatable results.
Quick Setup and Operation – Simple clamping system reduces setup time and improves productivity.
Durable Alloy Steel Body – Case hardened to HRC 55 ±2 for superior wear resistance and extended service life.
Applications
CNC Milling Machines
Vertical and Horizontal Machining Centers
Precision Grinding Operations
Drilling and Tapping Fixtures
Multi-Part and High-Density Workholding Setups
Manufacturing of Precision Components
