Steel-Smith
-
Steelsmith Medium Duty Adjustable Latch
-
-
-
Steelsmith Steelsmith Pull Action Clamp PAV Series
-
-
Steelsmith Steelsmith Horizontal Hold Down Action H-225 & H-235 Series Clamps
Horizontal Hold Down Action (HTC-Series): The holding action in these types of Toggle Clamps is same as VTC-Series clamps. The outstanding characteristic is the low height design. Unlike the handle & the clamping bar of the VTC-Series, these of the H-Series clamps move in opposite direction. The holding capacities range upto 1,000 kgs. The clamping arm can be solid bar, U shaped or fixed hole type. The SF Series have solid hold down bar which has a fixed guide bush at its end for the spindle assembly. The SB Series have a "U" bar arm which the bolt retainer can be welded at any desired angle. The UB Series have a "U" bar arm which enables one or more spindles to be moved into any desired position along the arm.
-
Steelsmith Steelsmith Horizontal Hold Down Action H-215 Series Clamps
Horizontal Hold Down Action (HTC-Series): The holding action in these types of Toggle Clamps is same as VTC-Series clamps. The outstanding characteristic is the low height design. Unlike the handle & the clamping bar of the VTC-Series, these of the H-Series clamps move in opposite direction. The holding capacities range upto 1,000 kgs. The clamping arm can be solid bar, U shaped or fixed hole type. The SF Series have solid hold down bar which has a fixed guide bush at its end for the spindle assembly. The SB Series have a "U" bar arm which the bolt retainer can be welded at any desired angle. The UB Series have a "U" bar arm which enables one or more spindles to be moved into any desired position along the arm.
-
-
Steelsmith Steelsmith PAH TRIG Clamps
-
-
Steelsmith Medium Duty Non-Adjustable Latch (27Series)
-
-
Steelsmith Steelsmith Pull Action Clamp PA Series
-
Steelsmith HTC-LH-TRIG Series Clamps
-
-
Steelsmith PAH 27 TRIG Clamps
-
-
-
Steelsmith Steelsmith HTC-Series Medium/Heavy Duty-Package Size Clamps, Flanged Base
Straight Line Action (HTC-Series): The straight line action toggle clamps design uses a straight-line or push/pull, Toggle clamping action. The push/pull handle is easy to operate & moves the plungers of the clamp in and out along its axis. Most of these clamps can be locked in two positions, allowing you to use them as either push or pull clamps. These clamps are manufactured in a variety of models to accommodate a wide range of load rating.(45 kgs- 4,500 kgs) The SF Series have solid hold down bar which has a fixed guide bush at its end for the spindle assembly. The SB Series have a "U" bar arm which the bolt retainer can be welded at any desired angle. The UB Series have a "U" bar arm which enables one or more spindles to be moved into any desired position along the arm.
-
Steelsmith Steelsmith Pneumatic Swing Clamp Block Version
Features Block design permits the clamp to be mounted from three different faces. Grooves on one side for Reed switch mounting. Simple mounting preparation and easy installation with 2 or 4 mounting bolts. Specifications Material and Design: Material: Aluminum Alloy Body Finish: Black Anodizing Acting Type: Double Acting Force: 16-140 kgs Total Stroke: 27-32 mm Working Pressure: 4-7 Bar Swivel Angle: 90° ±2° Technical Details Model No Weight (Kgs) Piston Dia. (mm) Bore Dia. (mm) Swing Stroke (mm) Clamping Stroke (mm) Force in Kgs (5 kg/cm²) SC-25-PB-R / L 0.700 14 25 13 14 16 SC-32-PB-R / L 0.900 16 32 16 14 30 SC-40-PB-R / L 1.100 16 40 15 15 50 SC-50-PB-R / L 1.200 20 50 17 15 85 SC-63-PB-R / L 1.400 20 63 15 15 140 Dimensions Model No D Sq. A Clamped C G H J NCB L P SC-25-PB-R / L 16 50 35 6 M6x1.00 21 40 78 82 SC-32-PB-R / L 19 60 45 9 M8x1.25 21 45 90 96 SC-40-PB-R / L 19 70 55 9 M8x1.25 22 52 90 96 SC-50-PB-R / L 25 80 65 10 M12x1.5 25 66 100 105 SC-63-PB-R / L 25 90 80 10 M12x1.5 28 80 100 107
-
Steelsmith Steelsmith Pneumatic Swing Clamp Upper Flange Model
NPSU‐Series Pneumatic Swing Clamp Upper Flange Version Features Design Benefits: No fixture hole required. Cylinder can be bolted directly to the fixture. Easiest mounting preparation in the swing clamp line. Square flange design enables clamping on all four sides of the clamp. Suitable for clamping extra-large parts. Specifications Material and Design: Material: Aluminum Alloy Body Finish: Black Anodizing Acting Type: Double Acting Force: 16-140 kgs Total Stroke: 27-32 mm Working Pressure: 4-7 Bar Swivel Angle: 90° ±2° Technical Details Model No Weight (Kgs) Piston Dia. (mm) Bore Dia. (mm) Swing Stroke (mm) Clamping Stroke (mm) Force in Kgs (5 kg/cm²) SC-25-NPUF-R / L 0.700 14 25 14 14 16 SC-32-NPUF-R / L 0.800 16 32 14 14 30 SC-40-NPUF-R / L 0.850 16 40 14 14 50 SC-50-NPUF-R / L 1.000 20 50 14 15 85 SC-63-NPUF-R / L 1.200 20 63 15 15 140 Dimensions Model No D Sq. A Clamped C G H J NCB L P SC-25-NPUF-R / L 16 50 50 6 M6 23 25 50 87 SC-32-NPUF-R / L 19 60 60 9 M8 23 25 60 98 SC-40-NPUF-R / L 19 70 65 9 M8 26 25 65 103 SC-50-NPUF-R / L 25 80 75 10 M12 32 25 75 110 SC-63-NPUF-R / L 25 90 90 10 M12 35 25 90 110
-
Steelsmith Steelsmith Pneumatic Swing Clamp Lower Flange Model
PSF‐Series Pneumatic Swing Clamp Lower Flange Version Features Design Benefits: Cylinder can be bolted directly to the fixture. Easiest mounting preparation in the swing clamp line. Square flange design enables clamping on all four sides of the clamp. Suitable for clamping extra-large parts. No Fixture Hole Required. Specifications Material and Design: Material: Aluminum Alloy Body Finish: Black Anodizing Acting Type: Double Acting Force: 16-140 kgs Total Stroke: 26-29 mm Working Pressure: 4-7 Bar Swivel Angle: 90° ±2° Technical Details: Model No Weight (Kgs) Piston Dia. (mm) Bore Dia. (mm) Swing Stroke (mm) Clamping Stroke (mm) Force in Kgs (5 kg/cm²) SC-25-PLF-R / SC-25-PLF-L 0.400 14 25 12 14 16 SC-32-PLF-R / SC-32-PLF-L 0.700 16 32 12 14 30 SC-40-PLF-R / SC-40-PLF-L 0.850 16 40 12 14 50 SC-50-PLF-R / SC-50-PLF-L 1.300 20 50 14 15 85 SC-63-PLF-R / SC-63-PLF-L 1.800 20 63 14 15 140 Dimensions: Model No D Sq. A Clamped C G H J MCB L P SC-25-PLF-R / L 16 35 30 8 M8x1.25 23 30 40 65.5 SC-32-PLF-R / L 19 50 50 9 M8x1.25 23 44 54 71 SC-40-PLF-R / L 19 55 50 9 M8x1.25 26 48 58 75 SC-50-PLF-R / L 25.4 65 70 10 M10x1.5 26 55 68 80 SC-63-PLF-R / L 25.4 75 70 10 M10x1.5 30 64 80 86
-
Steelsmith Steelsmith Pneumatic Swing Clamp Threaded Body Model
Pneumatic Swing Clamp Threaded Body Model - Right Swing Threaded Body Model - Left Swing Key Features: Body thread for precise cylinder height positioning. Threaded port connection. Available with two flange nuts. Material Specifications: Material: Aluminum Alloy Body Finish: Black Anodizing Acting Type: Double Acting Force: 16-140 kgs Total Stroke: 28-30 mm Working Pressure: 4-7 Bar Swivel Angle: 90° ±2° Technical Table: Model No Weight (Kgs) Piston Dia. (mm) Bore Dia. (mm) Swing Stroke (mm) Clamping Stroke (mm) Force in Kgs (5 kg/cm²) Dimensions A (Clamped) B C D E SC-25-PT-R / SC-25-PT-L 0.800 14 25 14 14 16 76 70 10 16 35 SC-32-PT-R / SC-32-PT-L 1.100 16 32 14 16 30 83 79 13 19 40 SC-40-PT-R / SC-40-PT-L 1.250 16 40 14 15 50 87 83 13 19 45 SC-50-PT-R / SC-50-PT-L 1.700 20 50 14 14 85 92 87 13 25 50 SC-63-PT-R / SC-63-PT-L 2.200 20 63 15 15 140 97 92 13 25 56 Dimensions (Contd.): Model No G H J L M P S SC-25-PT-R / SC-25-PT-L M8x1.25 M5x0.8 9 58 M40 x 1.5 SC-32-PT-R / SC-32-PT-L M8x1.25 G1/8 11 70 M50 x 1.5 SC-40-PT-R / SC-40-PT-L M8x1.25 G1/8 11 75 M55 x 1.5 SC-50-PT-R / SC-50-PT-L M12x1.5 G1/8 12 85 M65 x 1.5 SC-63-PT-R / SC-63-PT-L M12x1.5 G1/8 15 105 M80 x 1.5
-
Steelsmith HTC TRIG Clamps
-
Steelsmith HTC-PS-TRIG Series Clamps
-
Steelsmith HTC-U-TRIG Series Clamps
-
Steelsmith VTC-U-TRIG
-
-
-
-
-
Steelsmith PAH 38 TRIG Clamps
-
-
-
-
You have seen 36 out of 63 products
